Floating Point Visually Explained

While I was writing the Wolfenstein 3D book[1], I wanted to demonstrate how much of a handicap it was to work without floating points. My attempts at understanding floating points using canonical[2] articles[3] were met with resistance from my brain.

I tried to find a different way. Something far from $(-1)^S * 1.M * 2^{(E-127)}$ and its mysterious exponent/mantissa. Possibly a drawing since they seem to flow through my brain better.

I ended up with what follows and I decided to include it in the book. I am not claiming this is my invention but I have never seen floating points explained this way so far. I hope it will helps a few people like me who are a bit allergic to mathematic notations.

How Floating Point are usually explained

In the C language, floats are 32-bit container following the IEEE 754 standard. Their purpose is to store and allow operations on approximation of real numbers. The way I have seen them explained so far is as follow. The 32 bits are divided in three sections:

Floating Point internals. The three sections of a floating point number. So far, so good. Now, how numbers are interpreted is usually explained with the formula:

$$ (-1)^S * 1.M * 2^{(E-127)} $$
How everybody hates floating point to be explained to them.

This is usually where I flip the table. Maybe I am allergic to mathematic notation but something just doesn't click when I read it. It feels like learning to draw a owl.

Floating-point arithmetic is considered an esoteric subject by many people.

- David Goldberg

A different way to explain...

Although correct, this way of explaining floating point will leaves some of us completely clueless. Fortunately, there is a different way to explain it. Instead of Exponent, think of a Window between two consecutive power of two integers. Instead of a Mantissa, think of an Offset within that window.


The three sections of a floating Point number. The window tells within which two consecutive power-of-two the number will be: [0.5,1], [1,2], [2,4], [4,8] and so on (up to [$2^{127}$,$2^{128}$]). The offset divides the window in $ 2^{23} = 8388608 $ buckets. With the window and the offset you can approximate a number. The window is an excellent mechanism to protect from overflowing. Once you have reached the maximum in a window (e.g [2,4]), you can "float" it right and represent the number within the next window (e.g [4,8]). It only costs a little bit of precision since the window becomes twice as large.

The next figure illustrates how the number 6.1 would be encoded. The window must start at 4 and span to next power of two, 8. The offset is about half way down the window.



Value 6.1 approximated with floating point.

Precision

How much precision is lost when the window covers a wider range? Let's take an example with window [1,2] where the 8388608 offsets cover a range of 1 which gives a precision of $\frac{(2-1)}{8388608}=0.00000011920929$. In the window [2048,4096] the 8388608 offsets cover a range of $4096 - 2048 = 2048$ which gives a precision of $ \frac{4096-2048}{8388608}=0.0002 $.

An other example

Let's take an other example with the detailed calculations of the floating point representation of a number we all know well: 3.14.

Which in binary translates to:


3.14 floating point binary representation. The value 3.14 is therefore approximated to 3.1400001049041748046875. The corresponding value with the ugly formula:

$$ 3.14 = (-1)^0 * 1.57 * 2^{(128-127)} $$

And finally the graphic representation with window and offset:


3.14 window and offset.


I hope that helped :) !
